Clamp AC Leakage Current Tester with Measuring Range 0.00mA to 600A High Accuracy Ac Leakage Current Sensor clamp Meter Resolution 0.01mA Circuit Voltage Lower Than AC600V

Introduction ETCR040 High Accuracy Clamp AC Current Sensor use permalloy magnetic cores, with small size, high accuracy, good stability, strong anti-interference ability characteristics. It is applied with double shield technology, which insure strong anti-interference ability. ETCR040 High Accuracy Clamp AC Current Sensor is widely applied in AC current leakage, current, power and energy measurement with high precision and small phase error of electricity, communications, meteorology, railway, oilfield, construction, measurement, scientific and research teaching unit, industrial and mining enterprises, which can be connected to a variety of high precision digital multi-meter and data recorder. Specification Function：AC leakage and current detection Test model：Clamp CT, Current induction output Clamp size：35mm×40mm Range：0.00mA-600A Resolution：0.01mA Accuracy：0.5%(23c±3c below 70%RH) Current transformer：Around 1A/1mA Dimension：120mm×70mm×33mm Circuit voltage：Lower than AC600V Lead length：2m Weight：100g Working environment：-20c-50c below 80%rh Storage environment：-10c-60c below 70%rh Insulation strength：AC2kV/rms (between core and shell) Safety rules：IEC1010-1, IEC1010-2-032, Pollution degree 2 CATiii(600V) Accessary：Sensor:1PC

• ◆Function：AC leakage and current detection
• ◆Test model：Clamp CT, Current induction output
• ◆Clamp size：35mm×40mm
• ◆Range：0.00mA-600A
• ◆Resolution：0.01mA Accuracy：0.5%(23c±3c below 70%RH) Current transformer：Around 1A/1mA Dimension：120mm×70mm×33mm Circuit voltage：Lower than AC600V
