Solidremote 12V - 24V Secure Wireless RF Remote Control Relay Switch Universal 2-Channel Receiver with 2 Transmitters for Garage Door Openers, LED Lights etc (KIT-1)
$21.99
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by adherents.xylofutur.fr
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$21.99
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by adherents.xylofutur.fr
Free 30-day returns Details
Product details
| Management number | 219010738 | Release Date | 2026/05/03 | List Price | $8.80 | Model Number | 219010738 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- SECURE # Rolling code key fob device offers better security and far more code combinations (more than 18 quintillion - 18 x 10^18 possibilities, nearly a trillion more than typical fixed code or so-called learning code ones) and built on new platform using higher RF sensitivity -113dBm superheterodyne module for better long range and more stable performance.
- EASY & FLEXIBLE # Two independent relay channels can either work together (in latching) for polarity reversing or individually (in pulse / hold) to control different electronics, such as one channel for garage door controller unit, the other for entry lights. Easy programming & easy to use DIP switches working mode selection between pulse / momentary, hold / toggle and latching mode.
- ENCLOSURE # Designed to work both indoor and outdoor, default enclosure supplied protects the inner radio receiver circuit board safe from rain or other tough weather, while customer can also use chemical glue or epoxy adhesive to seal the wiring holes after setup, providing IP55 equivalent waterproof protection level. Mounting holes are provided for easy installation to walls etc using screws.
- INTERFACE # 3-Level efficient switching power supply system. Our 202U receiver board accepts 12 volts - 24 volts AC or DC wide supply voltage range (min. current rating is 110mA@12V DC). Each relay can switch up to 10A @14V DC or 10A @125V AC for resistive load (6A @14VDC for inductive load). Built-in small DC motor / solenoid polarity reversing control capability by using interlock latching mode and both relays.
- APPLICATIONS # Used in anti-theft alarm control panels, home automation systems, short and long range turn devices on / off wirelessly, lifts, boats, marine, winches, motor-driven curtain, roller blinds, overhead garage door & gate barriers, motorcycles, vehicles, cars, truck, industrial and agricultural electrical control such as water pumps & sprayer, electric door release locks, windows, manual switches extender, LED lighting lamp bulbs and strips, entrance and access control etc.
| UPC | 708296998994 |
|---|---|
| Model | SR-RCS-202U |
| Wattage | 120 watts |
| Brand Name | Solidremote |
| Unit Count | 1.0 Count |
| Part Number | KIT-1 |
| Coil Voltage | 12 Volts |
| Contact Type | Electrical |
| Manufacturer | Solidremote Technologies Ltd |
| Mounting Type | Wall Mount |
| Connector Type | 3-pin Terminal Block Connector |
| Current Rating | 10 Amps |
| Operation Mode | Automatic |
| Contact Material | Steel |
| Included Components | 1 x 202U receiver + 2 x TX134 remotes + 1 x instruction sheet |
| Number of Terminals | 3 |
| Contact Current Rating | 10 Amps |
| Maximum Switching Voltage | 24 Volts |
| Minimum Switching Voltage | 12 Volts (DC) |
